85434 /35 /36

Pneumatically operated pump models for use with single-line systems

Single-line air-operated intergrated grease pump model 85434

All models are air-operated, positive-displacement pumps delivering a maximum volume by means of a single stroke of the pump. Solenoid air valves and adjustable, solid-state time controls are integrated into the pump body. These pumps are designed to deliver grease to single-line metering devices and include a special high-volume refill fitting. Acrylic reservoirs are available in several sizes. Integrated controls feature LED indicators for “Power On”, “Pump On” and “Alarm,” along with a membrane-type, “Manual Lube” switch.

Features and benefits:

  • Integrated, adjustable, solid-state time controls with LED indicators
  • Integrated solenoid air valves
  • High-volume refill fitting
  • Suitable for use with single-line metering devices
  • Technical features
    Function principlepneumatically operated piston pump
    (single-stroke)
    Outlets1
    Metering quantity depending on model
    85434 / 8543518,70 cm³/stroke1.14 in³/stroke
    8543635,20 cm³/stroke2.15in³/stroke
    Lubricantgrease NLGI 0, 1, 2
    Operating temperature-23 to +65 °C-10 to +150 °F
    Operating pressuremin, 82 bar
    max. 240 bar
    min. 1200 psi
    max. 3500 psi
    Reservoir2,0 kg4.5 lb
    Material (reservoir)acrylic
    Connection outlet1/4 NPTF (F)
    Voltage depending on model
    85434 / 85436120 V AC
    85435240 V AC
    Transmission ratio depending on model
    85434 / 8543531:1
    8543625:1
    Dimensions627 × 166 × 460 mm24.7 × 6.52 × 18.11 in
    Mounting positionvertical
